Lidar is becoming a tool that is frequently being used in vehicles. While once thought of as something that would find a use mostly in autonomous driving, lidar has already found a home in advanced driver assistance systems (ADAS), which is a growing feature on almost all automobiles — gas or electric.
And it isn’t just on the luxury side of vehicles either, even budget friendly vehicles are getting the ADAS treatment like forward collision warnings, adaptative cruise control, emergency braking, high beam assist and lane departure warnings.
As technology improves and the cost of lidar and other electronic systems falls, more ADAS features will continue to find their way into vehicles.
This year, Hesai rolled out its ATX lidar, a low-cost basic unit that can be integrated into many vehicles due to its price point.
The following is a partial deep dive into the Hesai ATX lidar conducted by TechInsights.
Summary
- No display
- 672 KB embedded SRAM
Availability: China
Released: March 2025
Price: $4,847
Target market: Automotive, imaging
Main board
The main board of the Hesai ATX lidar system contains the main processor and memory as well as other electronic components including:
- Infineon’s 32-bit microcontroller with memory
- Texas Instruments’ dual-step down converter, high-voltage boost converter and 3.3 voltage reference IC
- 3peak’s dual 5 amp high-speed, low-side gate driver
- HesaiTech’s differential ADC driver and analog switch
- Efinix’s FPGA
- Renesas’ programmable mixed signal matrix
- Winbond’s serial flash memory
(Learn more about microcontrollers on Globalspec.com)
The motor board found inside the Hesai ATX lidar. Source: TechInsights
Motor board
The electronic components found on the Hesai ATX lidar motor board include:
- Monolithic Power Systems’ BLDC motor driver
- SGMicro’s high speed comparator
- Texas Instruments’ dual Schmitt-trigger buffer
(Learn more about mixed-signal components on Globalspec.com)
Some of the components found inside the Hesai ATX lidar. Source: TechInsights
Major components
- $9.72 — VCSEL Array — Unknown (Qty: 1)
- $8.12 — Main Frame (Qty: 1)
- $4.99 — 32-bit Microcontroller w/Memory — Infineon (Qty: 1)
- $4.62 — 10 Layer Buildup FR4/HF — Unknown (Qty: 1)
- $4.43 — Lens #2 (Qty: 1)
- $4.18 — Top Cover (Qty: 1)
- $3.91 — FPGA — Efinix — Ti60 (Qty: 1)
- $3.81 — Lens #1 (Qty: 1)
- $3.77 — Transmitter Mirror (Qty: 1)
- $3.59 — Receiver Mirror (Qty: 1)
